| General |
| Product Type |
LED-backlit LCD flat panel display |
| Power Consumption Operational |
106 Watt |
| Diagonal Class |
75" |
| Diagonal Size |
74.6" |
| Commercial Use |
Yes - interactive |
| Combined With |
Touchscreen (multi touch) / optional slot-in PC capability |
| Series |
IFP33 Series |
| Operating System |
Android OS 13 |
| TV Tuner |
No tuner |
| TV Tuner Presence |
No |
| Sensors |
Light sensor |
| Video Interface |
HDMI |
| PC Interface |
VGA (HD-15) |
| Modes |
Landscape mode |
| Width |
170.9 cm |
| Depth |
8.8 cm |
| Height |
102 cm |
| Weight |
47.3 kg |
| Display |
| LCD Display Technology |
IPS |
| Colour Support |
1070000000 colours |
| Resolution |
3840 x 2160 |
| Display Format |
4K UHD (2160p) |
| Image Aspect Ratio |
16:9 |
| Frame Rate & Enhancement Technology |
60 Hz Refresh Rate |
| LCD Backlight Technology |
Direct LED |
| Coating |
7H Hard, anti-glare |
| Dynamic Contrast Ratio |
5000:1 |
| Brightness |
450 cd/m² |
| Viewing Angle |
178 degrees |
| Viewing Angle (Vertical) |
178 degrees |
| Touchpoints Qty |
40 |
| Response Time |
8 ms |
| Backlight Life |
50,000 hours |
| Features |
Open Pluggable Specification slot, Ultra Fine Touch Technology (UFT), WiFi slot, USB SmartPort, myViewBoard Display software, picture-in-picture (PIP), picture-by-picture (PBP) |
| Stands & Mounts |
| Flat Panel Mount Interface |
800 x 400 mm |
| VESA Compatibility |
Yes |
| Media Player |
| USB Port |
Yes |
| Configuration |
ARM Cortex-A55 Quad-Core - 8 GB DDR4 - 128 GB |
| Remote Control |
| Type |
Remote control |
| Battery Form Factor |
AAA type |
| Battery Included |
Yes |
| Audio System |
| Speaker System |
2 speakers |
| Output Power / Total |
36 Watt |
| Speakers |
2 x main channel speaker - 18 Watt |
| Network & Internet Multimedia |
| Connectivity |
LAN |
| LAN Protocol |
Fast Ethernet |
| Connections |
| Connector Type |
3 x HDMI input
HDMI output
VGA input
Audio input
Audio output
2 x LAN
RS-232 input
2 x USB 3.0 - front
2 x USB 3.0 - rear
USB 2.0 - rear
USB - front
USB - rear
SPDIF output
USB-C with DisplayPort 1.2, Ethernet 100M, 65W Power Delivery - front |
| Miscellaneous |
| Included Accessories |
2 touch pens, RS232 adapter, 5 clamps, camera plate, 8 x screws, remote control, myViewBoard WhiteBoard software |
| Cables Included |
USB touch cable - 3 m
HDMI cable - 3 m |
| Compliant Standards |
FCC, ICES-003, CE/EMC, LVD, CB, RoHS, Green BOM, RoHS DoC, ERP, REACH SvHC, DOC, Energy Efficiency Label (EEL), WEEE, BSMI, BIS |
| Power |
| Power Device |
Power supply |
| Input Voltage |
AC 100-240 V |
| Power Consumption (Off Mode) |
0.5 Watt |
| Dimensions & Weight (Shipping) |
| Width (Shipping) |
186.3 cm |
| Depth (Shipping) |
22.5 cm |
| Height (Shipping) |
114 cm |
| Weight (Shipping) |
60.55 kg |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
40 °C |
| Humidity Range Operating |
20 - 80% RH (non-condensing) |
